Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry

Name: Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry
Brand: hongtai
Price: 500.00 USD

$Wholesale Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry from china suppliers$

Place of Origin : Henan, China

Shape : Block

Material : alumina

SiO2 Content (%) : -

Al2O3 Content (%) : 94

MgO Content (%) : -

CaO Content (%) : -

Refractoriness (Degree) : Super-Class (Refractoriness> 2000°)

CrO Content (%) : -

SiC Content (%) : -

Model Number : customiazation

Brand Name : hongtai

Processing Service : Cutting, grinding, assembly

Product name : Excellent Performance Fused Cast Corundum Refractory Brick

Application : Glass Kiln

MOQ : 10 pieces

Price : $500.00/pieces >=10 pieces

Contact Now

Product Description

Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry

Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry are made of high-purity alumina as raw material, and a small amount of soda ash is introduced, and melted at a temperature of 2000~2200℃. The particle mix should be based on the principle of the most compact stacking, and a multi-level ratio should be adopted to increase the amount of fine powder, promote the sintering of the brick, and increase the volume density of the product.
According to the crystal phase structure, Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry is divided into three categories: α-β corundum bricks, β-corundum bricks andα-corundum bricks. Because of the use of high-purity raw materials, few impurities, and almost no matrix glass phase, Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry has superior low pollution performance to glass liquid. Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry can meet the different use requirements of glass kilns and metallurgical electrolytic cells.

$Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry$

Details Images

Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry

1.Fused α-corundum bricks;
α-Al2O3 is the only stable crystal of alumina at high temperature, with a density of 3.99~4.00g/cm3, a melting point of 2050℃, a Mohs hardness of 9, and belongs to the hexagonal crystal system.
Fused α-corundum bricks are mainly composed of α-type corundum, with no glass phase in the composition, and only a small amount of β-corundum. Suitable for dissolving borosilicate glass, opal glass and melt containing sulfate. However, the glass erosion resistance of α-corundum bricks will decrease rapidly at a high temperature of 1600℃, so some borosilicate glass kilns tend to use fused quartz bricks.
2. α-β corundum bricks;
The main component is Al₂O₃ (containing 94.5% to 96.5%), and the crystal phase structure is composed of 45% to 55% α-Al₂O₃ phase and 45% to 60% β-Al₂O₃ phase.The interlacing of the two crystal phases constitutes a very dense organizational structure with excellent alkali resistance.
There is only a small amount of glass phase in the refractory brick, which will not seep out and pollute the glass melt when used.
It is an ideal material for the pool wall, kiln bottom and float glass melting furnace launder of the glass melting furnace cooling part.
3. β-corundum brick;
β-Al₂O₃ is another metamorphosis of alumina, with a molecular formula of Na₂O·11Al₂O₃, a relative density of 3.30-3.40, a Mohs hardness of 6, and a Na₂O content of up to 7% dissolved in β-Al₂O₃. Therefore, strictly speaking, β-Al₂O₃ cannot be regarded as a polycrystalline metamorphosis of Al₂O₃, but should be an aluminate group.
(1) The strength of β-corundum brick is relatively low; products composed of β-Al₂O₃ crystals have low structural strength due to the loose lattice.
(2) Strong resistance to alkali vapor corrosion; since Al₂O₃ is saturated with sodium above 2000℃, it shows extremely high corrosion resistance to alkali vapor.
(3) The thermal shock stability of β-corundum brick is also the best among fused-cast bricks.
(4) Reaction with SiO2 causes volume shrinkage; when in contact with SiO2, β-corundum easily turns into α-corundum, resulting in a larger volume shrinkage and causing cracks in the bricks.

$Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry$

Characteristic

Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry

Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry has the characteristics of high refractoriness, high load softening point, high thermal shock stability, etc. It has good erosion resistance and wear resistance at high temperature, and can withstand the erosion of metal liquid and slag. In addition, the refractory brick also has excellent mechanical properties, such as high hardness and high flexural strength.

$Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry$

Product Usage

$Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry$

- Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry usage introduction

Highly glass erosion resistance good wear resistance fused corundum brick are mainly used for channels, spouts and working ends of floating glass furnace.

$Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry$

Packing&Shipping

$Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry$

Packing Details of Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry

Batch goods of Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry:

1.International standard seaworthy exporttable packing.
2.Wooden pallet.
3.Wooden/bamboo case(box).
4.Further packing information will be based on customer"s requirements.

Samples of Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry:

1.The sample will be send by International sxpress FEDEX/DHL/UPS/TNT.

2.The goods are transport by shipping.

Company Introduction

Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry

Henan Hongtai Kiln Refractory Co., Ltd. is established in 2002, located in Xinmi City, 40kilometers southwest of Zhengzhou City in Henan Province, close to Jingguang, Longhai railway lines, with road transport facilities. Rich resources of Refractory materials,adequate and qualified fuel in this area, provide unique conditions for refractory production, shipping and refractory industry development. Main products include different kinds of refractory brick:Fire Clay Brick, High Alumina Brick, Light Weight
Insulating Brick,Corundum Brick,Mullite Brick,AZS Bricks, Refractory Balls ,Refractory concrete,refractory castable,Acid resistant brick etc.They are widely used in Iron and steel, Nonferrous metals, Building materials(Cement,Glass,Ceramic),Petrochemical,Energy & Incineration etc industries. Our products have been exported to United States, Germany, Italy, Spain, Mexico, Brazil, South Korea,India,Turkey,Vietnam,Malaysia and Kazakhstan etc.“Science-Technology Innovation, Cooperation for Win-Win”

$Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry$

Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry

Our Services & Strength
1.Strong professional:
Our company has thirty years producing experience in refractory products. Our manager will supervise on a various refractorys production materials, process control, quality supervision and package delivery, and ensure the products are 100% qualified.
2.Annual supply:
Our company has passed ISO9001 quality management system certification and SGS certification. And the annual supply of shaped and unshaped refractory product is 28, 800-35, 000 tons.
3.Export experiences:
Now we have gained a global sales network reaching United States, Germany, Italy, Spain, Mexico, Brazil, South Korea,India,Turkey,Vietnam,Malaysia and Kazakhstan etc, and so on.
4. Production equipment:
Production and testing equipments are new, complete and automated or semi- automated. Such modern facilities and equipments have provided the fine technical guarantee for the production and testing.
5. Testing equipment:
Our company's testing equipments as follows:
High Temperature RUL Tester
Bulk Density Tester
The Pressure Tester
Refractoriness Tester

$Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry$

FAQ

Excellent High Temperature Performance Fused Cast Corundum Refractory Brick for Glass Industry

Q1: Are you a manufacturer or trader ?
A1: Manufacturer, some time we help our clients to purchase relevant products as a trader.
Q2: What's the MOQ?
A2. No limitation.
Q3: Can we visit your factory?
A3: Of course ,welcome at any time,seeing is believing
Q4: What's your payment terms?
A4: Negotiation, Accoridng to your inquiry products quality and quantity .
Q5: Did your factory accept customization ?
A5: Professional technology teams and engineers all can satisfy you.
Q6: How do you guarantee quality?
A6: For every production processing,we have complete QC system for the chemical composition and Physical properties.After production,all the goods will be tested ,and the quality certificate will be shipped along with goods. Accept SGS inspection or any third party you as sign .
